| MODEL |
HR-100A / HR-100AZ |
HR-150A / HR-150AZ |
HR-250A / HR-250AZ |
| Weighing capacity |
102g |
152g |
252g |
| Minimum weighing value |
0.1mg |
| Repeatability/Std Dev |
0.01mg |
0 to 200 g: 0.1 mg
200 to 252 g: 0.2 mg |
| Linearity |
±0.2mg |
±0.3mg |
| Stabilization Time (set to FAST) |
Approx. 2 second* |
| Sensitivity Drift |
±2ppm/°C (10°C-30°C/50°F-86°F) |
| Calibration |
HR-A |
External |
| HR-AZ |
Internal |
| Clock and calendar function |
HR-A |
No |
| HR-AZ |
Yes |
| Operating temperature |
5 to 40°C (41 to 104°F), 85%RH or less (non-condensing) |
| Display Refresh rate |
5 times / second or 10 times / second, selectable |
| Measurement Units (Display mode) |
g, mg, oz, ozt, ct, momme, dwt, GN, tael, tola,
pieces (counting mode), % (percent mode), DS (density mode), user definable functions |
| Counting mode |
Minimum unit mass = 0.1mg / Number of samples = 10, 25, 50 or 100 pieces |
| Percent mode |
Minimum 100% ref. mass = 10.0 mg / Minimum 100% display = 0.01%, 0.1%, or 1% (depends on the reference mass stored) |
| Standard interface |
RS-232C standard (see Accessories for more interface options) |
| Applicable calibration weight value |
100g, 50g |
150g, 100g, 50g |
250g, 200g, 100g, 50g |
| Weighing pan diameter |
Ø90 mm |
| External dimensions |
198 (W) x 294 (D) x 315 (H) mm / 8 (W) x 12 (D) x 12.4 (H) in |
| Net weight |
HR-A |
3.5 kg / 7.8 lb |
| HR-AZ |
3.9 kg / 8.9 lb |
| Power supply |
AC adapter |
| Power consumption |
Approx. 11 VA (supplied by the AC adapter) |
